| LX1 | |
| Outside size | 8350×4000×3200mm(L×W×H) |
| Inside size | 6900×3900×2650mm(L×W×H) |
| Entrance door | 3 folds,3000x2600 mm(W×H), bending steel door,cast aluminum hinge, tempered glass window |
| Emergency door | 650*2000mm(W*H),with pressure lock,with glass window,with step |
| Main System | |||
| Cabin system | Wall panel | -Sandwich style EPS 50mm,0.376mm thick steel, anti-flame and heat-insulation.-High quality galvanized steel roof panel. | |
| Basement | Optional | ||
| Ventilation system | Inlet fan | Optional | |
| Outlet fan | 1 set European-style exhaust air fan,the power is 5.5KW ,air capacity:18000m³/h. | ||
| Cabinet setting type | -Exhaust air from back downside,adopt powder quadrate steel frame , strong and beautiful .-Cabinet for the fan*1unit ,910mm height air duct *2units, -Elbow: 90°*1 unit | ||
| Airflow speed | On load 0.3m/s,ventilation rate:280time/h | ||
| Heating system | Optional : Movable infrared baking lamps(3 lamps or 6 lamps) | ||
| Lighting system | Ceiling lights | 8 groups*4 units=32 units*16W,LED lighting | |
| Side lights | Optional | ||
| Filtering system | Primary filter | Grade G2 plate type , filtering rate＞83% | |
| Floor filter | Multi-layer fiberglass filter,filtering rate＞70% | ||
| Control system | Control panel | Intelligent control system | |
| Function | Lighting,painting, Overload, lack of phase protection | ||
| Voltage/Frequency | 380V,50HZ,3 phase | ||
| Total power | 6 KW | ||
