LX-D3
|
||||||||
Outside size |
7000x5200x3400mm(LxWxH) |
|||||||
Inside size |
6900×3900×2650mm(L×W×H) |
|||||||
Entrance door |
3 folds，3000x2600 mm(W×H), bending steel door |
|||||||
Emergency door |
650*2000mm(W*H),equipped with handle lock |
|||||||
Main System |
||||||||
Cabin system |
Wall panel |
-Sandwich style EPS 50mm,0.4mm thick steel, anti-flame and heat-insulation. -High quality galvanized steel roof panel. |
||||||
Basement |
-Galvanized steel assemble,280mm high,with steel structure support,3 rows grills ,2 rows of diamond plates. -2 ramps,external setting,620*2000mm(W*L)/pc |
|||||||
Ventilation system |
Inlet fan |
2*3kw double-intake centrifugal fans, air capacity:10000m³/h for each set |
||||||
Outlet fan |
1*5.5kw double-intake centrifugal fans, air capacity:15000m³/h for each set |
|||||||
Cabinet setting type |
-Intake air from side upper ,adopt powder quadrate steel frame , strong and beautiful . -Cabinet for the fan*1unit ,air duct *2units, -Elbow:90°*1 unit |
|||||||
Heating system |
10 Units 3KW infrared heating lamps |
|||||||
Max temperature is 80 degree . |
||||||||
Rate of temperature increase : 15-20min from 20~80 degree . |
||||||||
Lighting system |
Ceiling lights |
8*4pcs*16w LED lighting |
||||||
Side lights |
5*2pcs*16w LED lighting. |
|||||||
Filtering system |
Primary filter |
Grade G2 plate type , filtering rate＞83% |
||||||
Ceiling filter |
EU5 grade high efficient filter,filtering rate＞98% |
|||||||
Floor filter |
Multi-layer fiberglass filter,filtering rate＞70% |
|||||||
Control system |
Control panel |
Intelligent control system |
||||||
Function |
Lighting, temperature time setting, painting, constant temperature painting, baking,emergency stop, failure indication, etc |
|||||||
Total power |
42KW |
|||||||
Voltage/ frequency
|
380V/220V ,50HZ/60HZ,3phase/1Phase |
|||||||
