Products Description
LX-D3




Outside size
7000*5200*3400mm(L*W*H)



Inside size
6900*3900*2650mm(L*W*H)



Entrance door
3 folds,3000*2600 mm(W*H), bending steel door, aluminum hinge, tempered glass window



Emergency door
650*2000mm(W*H),equipped with handle lock, observation window



Main System




Cabin system
Wall panel
-Sandwich style EPS 50mm,0.4mm thick color steel plate.
-High quality galvanized steel roof panel.




Basement
-Galvanized steel assemble,280mm high,with steel structure support,3 rows of 30*4mm grills ,2 rows of diamond plates.
-2 ramps,external setting,620*2000mm(W*L)/pc


Ventilation system
Inlet fan
2*3kw double-intake centrifugal fans, Each set air capacity:10000m³/h




Outlet fan
1*5.5kw double-intake centrifugal fans, model: YDW4.5S, Each set air capacity:15000m³/h



Cabinet setting type
-Intake air from side upper ,adopt powder quadrate steel frame , strong and beautiful.
-Cabinet for the fan*1unit ,air duct*2units.
-Elbow:90°*1 unit.



Airflow speed
On-load speed:0.35m/s,ventilation rate:280 time/h


Heating system
Electric
Adopt infrared heating system, 10 sets of 3KW single door far-infrared lamp. Maximum operating temperature: 80℃, heating rate
(20-80℃) : 15-20min.



Lighting system
Ceiling lights
8units*4pieces*16w LED Lighting




Side lights
5units*2pieces*16w LED Lighting


Filtering system
Primary filter
Grade G2 plate type , filtering rate>83%




Ceiling high efficient filter
EU5 grade high efficient filter,filtering rate>98%
Exhaust cotton filter


Control system
Control panel
Intelligent control system




Function
Lighting, temperature time setting, painting, constant temperature painting, baking,emergency stop, failure indication, etc


Total power
42 KW




Voltage/frequency380V/50HZ/3PH



















































Details Images
Galvanized Steel Wire Strands Gardening Steel Wire Galvanized Steel Flat Wire details
Galvanized Steel Wire Strands Gardening Steel Wire Galvanized Steel Flat Wire manufacture
Galvanized Steel Wire Strands Gardening Steel Wire Galvanized Steel Flat Wire supplier
Why Choose Us
Galvanized Steel Wire Strands Gardening Steel Wire Galvanized Steel Flat Wire manufacture
Galvanized Steel Wire Strands Gardening Steel Wire Galvanized Steel Flat Wire manufacture
Product Process
Galvanized Steel Wire Strands Gardening Steel Wire Galvanized Steel Flat Wire factory
Company Profile
Galvanized Steel Wire Strands Gardening Steel Wire Galvanized Steel Flat Wire details
Galvanized Steel Wire Strands Gardening Steel Wire Galvanized Steel Flat Wire factory
Galvanized Steel Wire Strands Gardening Steel Wire Galvanized Steel Flat Wire manufacture
Galvanized Steel Wire Strands Gardening Steel Wire Galvanized Steel Flat Wire factory
Galvanized Steel Wire Strands Gardening Steel Wire Galvanized Steel Flat Wire manufacture
Galvanized Steel Wire Strands Gardening Steel Wire Galvanized Steel Flat Wire manufacture
Exhibition
Galvanized Steel Wire Strands Gardening Steel Wire Galvanized Steel Flat Wire manufacture
Galvanized Steel Wire Strands Gardening Steel Wire Galvanized Steel Flat Wire manufacture
Packaging&Shipping
Galvanized Steel Wire Strands Gardening Steel Wire Galvanized Steel Flat Wire supplier
FAQ
Galvanized Steel Wire Strands Gardening Steel Wire Galvanized Steel Flat Wire supplier

Longxiang's CE certificate 7M cabina de pintura automatize spray booth paint booth car baking oven spray booth infrared auto paint box is the ultimate solution to your automotive painting needs. This top-of-the-line spray booth was fashioned with the utmost precision and expertise to provide impeccable leads to the shortest time that you can do.



The CE certificate 7M cabina de pintura automatize spray booth paint booth car baking oven spray booth infrared auto paint box boasts an impressive CE certification, which guarantees its quality and security, rendering it a car investment reliable, repair stores, automotive enthusiasts, and anyone whom values quality and effectiveness.



This Longxiang CE certificate 7M cabina de pintura automotriz spray booth paint booth car baking oven spray booth infrared auto paint box comes with the newest features and technologies being important for a flawless paint, including powerful infrared heating, high-quality filters, and an air flow robust system. These elements work with harmony which will make on a clean, safe, and painting environment consistent as well as other vehicles.



The CE certificate 7M cabina de pintura automotriz spray booth paint booth car baking oven spray booth infrared auto paint box features a spacious inside can accommodate large automobiles, such as trucks, buses, and vans, rendering it perfect for industrial-grade and commercial applications. The 7M cabina de pintura automotriz spray booth boasts a size of 7 meters, enough space two vehicles simultaneously.



Longxiang's CE certificate 7M cabina de pintura automotriz spray booth paint booth car baking oven spray booth infrared auto paint box also comes by having a variety of high rate safety features, such as an automated fire system, which instantly detects and extinguishes fires when you look at the booth. The booth can be built with a crisis end switch enabling one to shut the system down in the event of an emergency.



This CE certificate 7M cabina de pintura automotriz spray booth paint booth car baking oven spray booth infrared auto paint box functions for a low energy, rendering it an eco-friendly and cost-effective choice anyone trying to minimize their carbon footprint and save on power bills.
